0
Sale!
Li-BOX (48V – 100AH)
Original price was: ₨ 302,000.₨ 205,000Current price is: ₨ 205,000.
• This high-capacity 5.12kWh LiFePO4 battery offers exceptional longevity with over 8000 cycles using premium BYD cells, ensuring reliable long-term energy storage.
• Designed for versatility, it supports parallel connection of up to 16 units, and features a built-in Wi-Fi module for convenient remote monitoring.
• Equipped with comprehensive protection features and an IP54 rating, this battery is ideal for both floor-standing and wall-mounted installations in diverse environments.
Description
Battery Type LiFePO4
Normal Battery Voltage (VDC) 51.2V
Normal Capacity (25C, 0.2C) (WH) 5120WH
Voltage Window (VDC) 44.8~58.4V
Solar Charge Voltage (VDC) 56.2V
Max. Continue Discharge Current (A) 100
Max. Pulse Discharge Current (A) 100A 30 Sec
Max. Continue Charge Current (A) 100
Case Design Powerwall Design
Cycle Life (+25C 0.2 80%DOD) >6000 Cycles with 6 Years Warranty
Cell Equalizer Current (A) 1~5A Mox
Terminal M8
Storage Temperature 0°C~30°C
Storage Duration 3 months at 25°C
Safety Standard 3 months at 25°C
Safety Standard IP21
PROTECTION
Protection Over Charge Protection, over Discharge Protection, Over Current Protection, Short Circuit Protection, Over Temperature Protection
AMNIENT
Noise (dB) <40dB (1 Meter)
Working Temperature -20°C~+55°C
Humidity 0~95% (no condensation)
Sea Level (m) -1500
DIMENSION
LxWxH mm L625*W390*H210
Weight (NW Kg) 43.0Kg
Weight (GW Kg) 44.0Kg
